Size: 10.1"
This newest 5th-GEN industrial-grade touch screen display from Touch Think built with stable and reliable performance and high-quality assurance. It has passed a series of industrial standards of certification, suitable for heavy-duty industrial environments.
Product Color
Model: TPC101-M5
Products Features
• Touch Think 5th-GEN industrial monitor: 7mm front bezel
• High precision aluminum alloy die casting
• Independent research and development of industrial-grade display driver board
• Non-touch / capacitive touch / resistive touch screen for option
• 12-24V wide voltage power supply operation
• HDMI / VGA / DVI multi-signal automatic identification input
• Flexible installation types: panel mount, desktop, embedded, VESA-75/100.
Industrial Touch Screen Monitor Display
| Screen parameters | Screen size | 10.1 inch |
| Model | TPC101-M5 | |
| Resolution | 1280*800 | |
| Proportion | 16:10 widescreen | |
| Gray-scale response time | 5ms | |
| Panel Type Industrial | Control A+ style TFT | |
| Point distance | 0.264mm | |
| Contrast | 800:1 | |
| Backlight type | LED, life span ≥50000h | |
| Display color | 16.7M | |
| Visual angle | 160/160 (178° full view angle customizable) | |
| Brightness | 400cd/m2 (high brightness customizable) | |
| Touch-type | Resistive / capacitive / mouse control | |
| Number of touches | ≥ 50 million times | |
| Other parameters | Power Supply | 4A External Power Adapter |
| Power Performance | 100-240V, 50-60HZ | |
| Input voltage | 12-24V | |
| Anti-static | contact 4KV-air 8KV (can be customized ≥16KV) | |
| Power | ≤48W | |
| Anti-vibration | GB2423 standard | |
| Anti-interference | EMC|EMI anti-electromagnetic interference | |
| Dustproof and waterproof | Front panel IP65 dustproof and waterproof | |
| Housing Material | Black/Silver, Aluminum Alloy | |
| Installation method | Embedded, desktop, wall-mounted, VESA 75/100, panel mount, open frame | |
| Ambient temperature | <80%, non-condensable | |
| Working temperature | -10°C～60°C (-30°C～80°C customizable) | |
| Language menu | Chinese, English, German, French, Korean, Spanish, Italian, Russian, etc. | |
| O/I interface parameters | Signal Interface | DVI, HDMI, VGA |
| Power connector | DC with ring attachment (optional DC terminal block) | |
| Touch interface | USB | |
| Other interfaces | Audio input and output |
| Types | Customization Items | Customizable or Not |
| Appearance | Materials & structure | Yes |
| Product color | Yes | |
| Display size | Yes | |
| Installation types | Yes | |
| LOGO & Label | Yes | |
| Independent molding | Yes | |
| Screen | High brightness | Yes |
| Wide temperature operation | Yes | |
| Anti-glare, explosion-proof, full viewing angle, definition, touch screen types, | Yes | |
| Functional Modules | NFC, RFID, ID card reader, scanning module, magnetic stripe card reader, speaker, fingerprint module, Infrared induction, temperature measurement module, camera module, microphone, handset module, buttons, Iris module, interface module, relay module, transformer, alarm, photosensitive module, dual-band WiFi, 3G / 4G module, GPS positioning, etc. | Yes |
